      AVE 2 Birthing Bed Specification & Dimensions

      Here you will find all of the information regarding the specifications and dimensions for the AVE 2 Birthing Bed.

      Ave2 Hero

      Standard Specification:

      • Standard Leg Rests (pair)

      • Backup battery

      • Sliding foot section including the upholstery

      • Duocoat mattresses with double covering

      • Electric Trendelenburg and manual CPR positions

      • Infusion stand holder on both sides of the bed

      • Side rail with controls

      • Fixed panel with controls

      • Sliding stainless catch basin 4.5L

      • Handgrips (pair)

      • Castors 150mm, 1 x directional

      • Central brake

      • Equipotential pin

      • Mains cable

      Optional Extras:

      • Telescopic IV Pole

      • Supporting bar

      • Brackets for Supporting Bar

      Dimensions:

      Total length of lying area - 2122mm
      Width with Side Rails in Active Position: 980mm
      Width with Side Rails in Parked Positions: 960mm

      Maximum Height of seat section - 1143mm
      Maximum Height including Mattress: 600mm + 20mm
      Minimum Height including Mattress: 1050mm + 20mm

      Maximum Patient Load - 240Kg
      Safe Working Load - 255Kg
